SBR Rubber Sheet Manufacturer
Cost-Effective General Purpose Industrial Rubber Sheet for Wear & Protection Applications
SBR Rubber Sheet (Styrene-Butadiene Rubber Sheet) is a cost-efficient general-purpose synthetic rubber material widely used in industrial sealing, protection, and anti-wear applications.
It offers a balanced combination of:
- Good abrasion resistance
- Moderate tensile strength
- Stable mechanical performance
- Competitive cost advantage
And it can be one layer or multi-layers cloth inserted for increase strength and tear resistance.
Request Quote Request Technical Consultation Get Sample
product Technical Specifications
| Product Name | SBR Rubber Sheet | |||
| Product Code | ACS01001 | |||
| Length | 10m-20m | |||
| Width | 0.915m-2m | |||
| Thickness | 2mm+ in roll | 20mm-50mm in sheet | ||
| Customization | Size can be customized to your requirements. | |||
| Color | Standard: Black; Many colors available, white, red, green etc. | |||
| Insertion | Cotton, nylon, EP etc | |||
| Technical Data | Specific Gravity ( g/cm³ ) |
Tensile Strength ( Mpa ) |
Elongation ( % ) |
Hardness ( shore A ) |
| ACS01001-A |
1.70 |
2.0 | 150 | 65±5 |
| ACS01002-B |
1.60 |
2.5 | 200 | 65±5 |
| ACS01002-C | 1.50 | 3.0 | 200 | 65±5 |
| ACS01002-D | 1.45 | 4.0 | 200 | 65±5 |
| ACS01002-E | 1.40 | 5.0 | 250 | 65±5 |
| ACS01002-F | 1.35 | 8.0 | 300 | 65±5 |
| ACS01002-G | 1.25 | 10.0 | 350 | 65±5 |
| ACS01002-h | 1.20 | 14.0 | 400 | 55±5 |
 |
Top Rubber Layer Fabric Reinforcement Layer Bottom Rubber Layer |
According to the customer's requirements, a layer or several layers of the fabric from the below table will be inserted between various rubber sheets. EP Cloth Bead Cloth Cotton Mesh Cloth Plain Cotton Cloth Large-Mesh Cloth Small-Mesh Cloth Tear-Resistant Cloth ● Please consult us for thickness, cloth type, cloth layer. |
This allows the rubber to maintain flexibility while significantly improving mechanical strength.
Typical Problems It Solves
SBR Rubber Sheet is designed for general industrial protection needs:
- High cost of premium rubber materials in non-critical applications
- Frequent wear of basic sealing and gasket materials
- Short lifespan of low-quality industrial liners
- Surface damage in light-to-medium duty equipment
- Lack of cost-effective cushioning materials
Features & Benefits
- Good abrasion resistance for general industrial use
- Stable performance under moderate load conditions
- Cost-effective alternative to natural rubber
- Good flexibility and easy fabrication
- Suitable for cutting, punching, and molding
- Available in multiple hardness grades
Industrial Applications
SBR Rubber Sheet is widely used in general industrial environments:
- Gasket and sealing systems
- Anti-slip flooring layers
- Conveyor skirt boards
- Light-duty wear protection liners
- Construction cushioning pads
- Machinery vibration isolation (light load)
- Packaging and shock protection layers
- Automotive non-oil-contact components
Frequently Asked Questions
What is SBR rubber sheet used for?
It is widely used for sealing, anti-slip, cushioning, and general industrial protection.
What is the main advantage of SBR?
It offers a cost-effective solution with good abrasion resistance for non-critical applications.
What fabric materials are available?
Cotton, nylon, polyester and EP fabric options are available.
Can multiple fabric layers be inserted?
Yes. Single-layer, double-layer and multi-layer reinforcement can be customized.
Can SBR be used outdoors?
It has limited weather resistance; EPDM is recommended for outdoor UV exposure.
Can AOCHEN customize thickness and dimensions?
Yes. Custom sizes and specifications are available.
Do you provide samples?
Yes. Samples can be supplied for testing and evaluation.
What is your MOQ?
Please contact our sales team for specific project requirements.
